DENON - PMA-60

Introducing the Denon Design Series

Real Hi-Fi For Today's Lifestyles. The PMA-60 amplifier delivers true Denon sound, with outstanding performance despite its compact size.

Features

High quality

·       Equipped with a high-quality class D amplifier

The amplifier section incorporates Qualcomm_® DDFA_TM technology from Qualcomm. The output stage circuit has a discrete construction which realizes higher S/N and lower distortion compared to conventional class D amplifiers. Additionally, the high 50 W+50 W (4 Ω/ohms) output which exceeds the size of the housing lets you enjoy Denon’s ideal audio playback environment that delivers “delicate yet powerful sound”.

·       High Bitrate and High Sampling with Advanced AL32 Processing Plus

A high bitrate and high sampling has been achieved with Denon's unique data interpolation algorithm. 16 bit audio signals are converted to a high bitrate of 32 bit and 44.1 kHz sampling signals are up-sampled by 16x to achieve smoother recreation of sound waves. Data interpolation is also used, predicting interpolation points from a large number of surrounding points to provide audio as close as possible to the original sound. This elaborate restoration of data lost during digital recording achieves fine, distortion-free rendering, accurate sound localizing, rich bass and recreation that is faithful to the original sound.

High performance

·       Equipped with a USB-DAC function to support playback of high-resolution sound sources

This unit supports the playback of high resolution audio formats such as DSD (2.8/5.6/11.2 MHz) and PCM signals up to 384 kHz/32 bits.
It provides high quality playback of high resolution files into this unit from a computer via USB-B connection.

·       Compatible with a wide range of digital input equipment

This device is installed with two optical digital input interfaces and one coaxial digital input interface to enable connection to a variety of TVs and other digital input devices.

·       Wireless connection with Bluetooth enabled devices

You can connect Bluetooth enabled devices such as smartphones and tablets with this unit to listen to music while browsing email and Web sites in the Internet away from this unit. In addition, this unit supports high quality audio codecs, aptX Low Latency and AAC, to enjoy music and games with a powerful sound.

·       NFC function included that enables one touch connection

You can just touch this unit with an NFC enabled smartphone or tablet to turn on power to this unit and establish the Bluetooth connection.

·       Supports vertical installation

This unit can be installed vertically or horizontally. The display automatically rotates to match the installation orientation.

·       System remote control

This unit comes with a system remote control that can also operate the Denon's CD Player DCD-50.

Specifications

Audio section

Output performance

Digital input signal

Input performance

Bluetooth section

The actual communication range varies depending on the influence of such factors as obstructions between devices, electromagnetic waves from microwave ovens, static electricity, cordless phones, reception sensitivity, antenna performance, operating system, application software etc.

General
