Genele8340A SAM™ Studio Monitor
- Regular price
- Rs. 241,000.00
- Sale price
- Rs. 241,000.00
- Regular price
-
Couldn't load pickup availability
Description
Elevate the accuracy of your audio monitoring to a new level with the precision and adaptability of the 8340A Smart Active Monitor.
The unvarnished truth
Top professionals the world over in recording studios, post-production houses, digital edit suites, radio, TV and outside broadcasting have come to rely on the unvarnished truth of the 8340A. Its wide and stable sweet spot promotes accurate, reliable mix decisions, and its bulletproof durability is essential for mission-critical applications.
Truly optimised monitoring
As a Smart Active Monitor, the 8340A integrates closely with our GLM software via which it can be configured and calibrated for your listening environment, compensating for detrimental room influences to create a truly optimised monitoring solution from mono to immersive. So if you need to work in challenging acoustic spaces, the 8340A is your powerful but clever monitoring companion.
Technical Specification
| Category | Specification |
|---|---|
| Frequency Response | |
| Flat Range (±1.5 dB) | 45 Hz – 20 kHz |
| Low Cutoff (-6 dB) | 38 Hz |
| High Cutoff (-6 dB) | 22 kHz |
| SPL (Sound Pressure Level) | |
| Peak SPL (per pair) | ≥118 dB (1 m, in-room, with music material) |
| Short-Term Max SPL | ≥110 dB (100 Hz – 3 kHz, sine wave, 1 m) |
| Long-Term Max SPL | ≥100 dB (RMS, IEC weighted noise, with protection, 1 m) |
| Self-Generated Noise | ≤5 dB SPL (A-weighted, free field, on axis) |
| Weight | 8.4 kg (18.5 lb) |
| Dimensions | |
| Height | 350 mm (13 3/4 in) |
| Height with Iso-Pod | 365 mm (14 3/8 in) |
| Width | 237 mm (9 3/8 in) |
| Depth | 223 mm (8 3/4 in) |
| Enclosure | |
| Material | Die-cast aluminium |
| Type | Reflex port |
| Drivers | |
| Bass Driver | 165 mm (6 1/2 in) cone |
| Treble Driver | 19 mm (3/4 in) metal dome |
| Directivity | Vertical and Horizontal (not numerically specified) |
| Harmonic Distortion | 50–100 Hz ≤2%, >100 Hz ≤0.5% |
| Group Delay | 3.0 ms (Extended Phase Linearity OFF) |
| Amplifier Section | |
| Bass Amplifier | 150 W (Class D) |
| Treble Amplifier | 150 W (Class D) |
| Power Consumption | |
| ISS Active | ≤1 W |
| Idle | ≤12 W |
| Full Output | 180 W |
| Signal Processing | |
| Analog Input | 1 x XLR female (balanced, 10 kΩ) |
| Digital Input | 1 x XLR female (110 Ω) |
| Digital Output/Thru | 1 x XLR male (110 Ω) |
| Control Ports | 2 x RJ45 (CAT5) GLM network connectors |
