Delivering high SPL and extended LF response, the 7380A offers power, clarity and flexibility in equal measures.
High SPL, low distortion
Providing a level of performance normally associated with much larger enclosures, the 7380A subwoofer offers both high power and high SPL, with an extended low-distortion LF response and flexible bass management options. Comprehensive connectivity ensures that the 7380A is equally at home in stereo or multichannel environments, making it perfect for music, post, film or broadcast applications that demand powerful, dependable LF reproduction in a surprisingly compact form factor.
Configure, calibrate and control
The 7380A works closely with our GLM software, which allows all monitors and subwoofers in a system to be configured, calibrated and controlled. Offering access to advanced system auto-calibration and management, GLM’s powerful room compensation features enable the 7380A to be optimized for a wide range of acoustic environments, and permits both centralized and distributed bass management modes to be employed.
Technical Specifications
Frequency Response
Spec
Value
Low Cutoff (-6 dB)
16 Hz
High Cutoff (-6 dB)
100 Hz
Sound Pressure Level (SPL)
Peak SPL
≥123 dB (Random pink noise, half space, 1 m)
Short-Term Max SPL
≥119 dB (30–85 Hz, sine wave, half space, 1 m)
Self-Generated Noise
≤5 dB SPL (A-weighted, 1 m on axis)
Dimensions & Weight
Spec
Value
Height
685 mm (27 in)
Width
718 mm (28 1/4 in)
Depth
492 mm (19 3/8 in)
Weight
69 kg (152.1 lb)
Enclosure Type
Reflex port
Driver
Spec
Value
Bass Driver
381 mm (15 in) cone
Harmonic Distortion
≤1% (30–85 Hz, 2nd harmonic)
Amplifier Section
Spec
Value
Bass Amplifier Output
800 W (Class D)
Power Consumption
Operating Mode
Power Usage
ISS Active
≤2 W
Idle
≤40 W
Full Output
600 W
Signal Processing & Connectivity
Connection Type
Details
Analog Inputs
7 × XLR female (7.1 input, balanced, 10 kΩ)
Analog Outputs
7 × XLR male (7.1 output)
Digital Input
1 × XLR female (110 Ω)
Digital Output
1 × XLR male (110 Ω)
LFE Input / Output
XLR analog LFE input & output
GLM Control Ports
2 × RJ45 (CAT5) – GLM network
Link Connectors
Link In & Link Out
