Anthem P5 5-channel Power Amplifier

Regular price: Rs. 1,125,000.00
Sale price: Rs. 1,125,000.00
Regular price: ~~Rs. 1,125,000.00~~

Get free shipping on your order.

Anthem P5 5-channel Power Amplifier

2 In Stock

Ships in 24 Hours

All India shipping

Manufacturer's Warranty

Secure Payment

Description

Anthem P5 - Overview

General

Specification	Details
Inputs	5 Single-Ended, 5 Balanced, 1 Relay Trigger (3.5 mm Mono Jack)
Outputs	5 Pairs Speaker Binding Posts, 1 Relay Trigger (3.5 mm Mono Jack)

Performance Specifications

Specification	Details
THD+N (225 W into 8 Ω)	0.0007% at 1 kHz, 0.008% at 20 kHz
IMD	0.00019% (CCIF, 325 W into 8 Ω)
Power Bandwidth	10 Hz to 150 kHz (+0 -3 dB, 325 W into 8 Ω)
Frequency Response	20 Hz to 20 kHz (+0 -0.15 dB), 5 Hz to 100 kHz (+0 -2 dB)
Input Sensitivity (RCA and XLR 0 dB inputs)	1 Vrms in for 28.3 Vrms out (100 W into 8 Ω)
Input Impedance	18 kΩ (RCA), 22 kΩ (XLR)
Damping Factor	>600 at 20 Hz, 400 at 1 kHz (ref. 8 Ω)
Signal-to-Noise Ratio (S/N)	125 dB, A-weighted (ref. 325 W)
Crosstalk (between any two channels)	-140 dB (20 Hz), -80 dB (20 kHz)
Voltage Gain	29 dB
Slew Rate	40 V/µs

Switches

Specification	Details
Front Panel	Power (On/Off)
Rear Panel	On/Off Modes (Trigger, Manual, Auto), Inputs (RCA, XLR, XLR -6dB)

Power Output (Per channel, continuous RMS, 20 Hz to 20 kHz, <0.1% THD, one or all channels driven)

Impedance	1 Channel Driven	All Channels Driven
8Ω	325 W	325 W
4Ω	500 W	500 W
2Ω	675 W	675 W

Power Requirements

Specification	Details
Supply Voltage	105 to 130 V, 60 Hz
Power Consumption	2 x 1800 W

Dimensions

Specification	Details
Height	9-3/8 inches (23.8 cm) including feet
Width (Faceplate)	19-1/4 inches (49 cm)
Width (Chassis)	17-1/4 inches (43.8 cm)
Depth (including handles)	22-1/2 inches (57.2 cm)

Weight

Specification	Details
Weight (Unpacked)	130 lb (59 kg)

Peace of Mind, Guaranteed.

Up to 10 Years of Hassle-Free Warranty.

Many sellers offer products without service, but we’ve got you covered. Contact us to book your warranty, drop it in-store, or ship it to us for a refund or exchange for up to 10 years.
