UIW RCS III in-ceiling speakers reach new heights of sound reproduction, with deep, dynamic low-frequency response and smooth, controlled rolloff for seamless blending with subwoofers.
Wave Launch™ Technology
for a theater-like presentation
UIW Reference Series loudspeakers are fully enclosed and sealed with dense, acoustically inert, anti-resonant, anti-vibration Medite® wood. With the RCS III, you’ll hear loud, accurate, uncolored midrange and tight, powerful bass with no buzzing or sound leakage into walls and ceilings.
1" Aluminum Dome Tweeter
The RCSIII aluminum dome tweeter delivers a clear, precise high frequency response. Their ultralight, rigid construction enables them to play significantly higher frequencies than we can hear, providing effortless, distortion-free highs within and beyond the audible range.
Dynamic Midrange/Woofer
Most in-wall speakers lack the larger driver area of floor standing speakers. The RCSIII's two 4.5" midrange/woofer drivers match butyl rubber surrounds with rigid polypropylene cones in cast baskets to provide a much greater cone excursion than other comparably-sized drivers. The result is superior midrange and bass performance, wrapped in a compact, stealthy package.
Installation Flexibility Ready for Any Room
Whether new or existing construction, walls or ceilings, residential or commercial, UIW Reference Series loudspeakers feature simple, secure installations. From metal pivoting lock arms to paintable grilles and frames to fully sealed enclosures, Definitive Technology engineers designed speakers that put installation simplicity on equal footing with sound quality.
Fully Enclosed
for powerful sound where you want it
UIW Reference Series loudspeakers are fully enclosed and sealed with dense, acoustically inert, anti-resonant, anti-vibration Medite® wood. With the RCSIII, you’ll hear loud, accurate, uncolored midrange and tight, powerful bass with no buzzing or sound leakage into walls and ceilings.
Definitive Technology UIW RCS III Technical Specifications
|
Driver Complement
|
(1) 1" (2.54 cm) d (Round) - Tweeter
(2) 4.5" (11.43 cm) d (Round) - Mid/Woofer
(2) 5.25" (13.34 cm) d (Round) - Bass Radiator
|
|
Audio Quality
|
Total Frequency Response: 30 Hz → 30 Hz
Nominal Impedance: 8 ohms
Max Sensitivity (1 watt @ 1 meter): 92 dB
|
|
Peak Power Handling
|
250 watts
|
|
A/V Receiver Crossover Settings
|
Small (60 Hz)
|
|
Ethernet
|
Yes
|
|
Speaker Inputs
|
(1) Pair of Heavy Duty, Spring Loaded - NA
|
|
Shape
|
Rectangle
|
|
Dimensions
|
10.38" (26.37 cm) h x 10.38" (26.37 cm) w
|
|
Grille Dimensions
|
11.5" (29.21 cm) h x 11.5" (29.21 cm) w
|
|
Weight
|
13 lbs (5.9 kg)
|
|
Included Accessories
|
(1) Wall Mounting Template
(1) Paint Mask
(1) Paintable Grille
(1) Self Adhering Foam Gasket
|
