Description
UTB™ (Ultra Thin Bezel)
The Ci160CRds features KEF's Ultra Thin Bezel (UTB™) design, creating a discreet and elegant appearance once installed. The minimal visible rim allows the speaker to blend seamlessly into ceilings or walls, making it an ideal choice for applications where aesthetics are as important as performance.
Asymmetrical Tweeter Island
An asymmetrical tweeter island design provides wider off-axis sound dispersion, ensuring more consistent audio coverage throughout the listening area. This helps deliver balanced sound performance to listeners in different positions within the room.
Dual Aluminium Dome Tweeters with Tangerine Waveguides
The speaker incorporates dual 19mm (0.75-inch) aluminium dome tweeters paired with KEF's Tangerine Waveguide technology. This combination enhances high-frequency dispersion and clarity, delivering detailed and evenly distributed treble performance across a wider listening area.
Dual Voice Coil Extended Response Bass Driver
A 160mm (6.5-inch) bass driver with a dual voice coil design provides extended low-frequency performance and improved sound coverage. This configuration enables the Ci160CRds to reproduce rich, balanced audio from a single speaker location, making it particularly suitable for stereo sound applications in compact spaces.
Audio excellence, redefined
Drives even the most demanding speakers
A push-pull amplifier, delivering 80W/channel into 8 ohms and 160W/channel into 4 ohms, effortlessly accommodates a range of speaker types and impedances.
Seamlessly integrate high-resolution digital audio
Digital connections, including optical, coaxial, and USB-B, support up to 384kHz/32- bit. Ultra AL32 Processing waveform interpolation produces smooth, high-resolution sound.
Unlock your vinyl collection’s full potential
Advanced Amplifier Design
The PMA-3000NE delivers 80W/channel into 8 ohms and 160W/channel into 4 ohms. Its Advance UHC-MOS Single Push-pull Circuit and differential 1-stage amplifier drive demanding speakers with exceptional clarity and linearity.Ultra AL32 Processing
Denon's Ultra AL32 Processing uses interpolation algorithms to produce highresolution output. Supporting input signals up to 384kHz/32-bit, it upsamples for smoother waveforms and improved sound reproduction.
High Performance MMC/MC Phono Stage
The PMA-3000NE's phono stage supports both MM and MC cartridges for truest vinyl reproduction in any setup. A high-gain design and “simple and straight” circuitry minimize distortion for pure, detailed sound.
Digital Audio Inputs
The PMA-3000NE’s versatile digital connections, including optical, coaxial, and USB Type B, support up to 384kHz/32-bit and 11.2MHz DSD audio.
Analog Mode
Analog mode bypasses digital circuitry for a pure, all-analog sound. A Source Direct function bypasses the tone controls so that the signal path is as short and clean as possible, for enhanced clarity.
Key Technologies
Includes Ultra 32 Processing
Ultra AL32 Processing is the latest in analog waveform reproduction technology from Denon.
Technical Specifications
| Spec | Details |
|---|---|
| Model | PMA-3000NE |
| Dimensions (W × H × D) | 434 × 182 × 443 mm |
| Net Weight | 24.6kg (54.2 lbs.) |
| Available Finishes | Silver, Black |
| Rated Output Power | 80W + 80W (8Ω, 20Hz–20kHz, THD 0.07%)160W + 160W (4Ω, 1kHz, THD 0.7%) |
| Total Harmonic Distortion (THD) | 0.01% (Rated Output: –3dB, 8Ω, 1kHz) |
| Input Sensitivity – Phono | MM: 2.5mV / 47kΩMC: 200μV / 100Ω |
| Input Sensitivity – CD / LINE / RECORDER | 135mV / 19kΩ |
| Input Sensitivity – Power Amp Input | 1.0V / 15kΩ (EXT. PRE) |
| Signal-to-Noise Ratio | Phono (MM): 89dB Phono (MC): 74dB CD: 107dB |
| Power Consumption | 400W |
| Power Consumption (Standby) | 0.2W (TV Auto Play Off)0.4W (TV Auto Play On) |
| Power Amplifier Circuit | New UHC-MOS Single Push-Pull (7) |
| Preamplifier Circuit | Variable Gain Preamplifier (OP AMP) |
| Tone Controls | Bass: YesTreble: YesMid: NoBalance: Yes |
| Source Direct | Yes |
| Analog Amp Mode | Yes (Front Panel Button) |
| DAC Circuit | 4 × ES9018K2M DACs |
| Digital Processing | Ultra AL32 Processing |
| DAC Master Clock Design | Yes |
| Asynchronous Mode (USB-B Input) | Yes |
| Phono Input | Yes (MM / MC, Default: MM) |
| Analog Inputs / REC Out (RCA) | 4 / 1 (Gold-Plated)Brass-Machined Terminals for CD / PHONO / AUX / RECORDER |
| Optical Inputs / Outputs | 3 / 0 (Up to 192kHz / 24-bit) |
| Coaxial Inputs / Outputs | 1 / 0 (Up to 192kHz / 24-bit) |
| Speaker Terminals | AVR-A1H Type Gold-Plated with Cover |
| Headphone Output | 1 (Speakers Automatically Mute When Headphones Are Connected) |
| Remote Control | Yes |
| Remote Control Bus Terminal | Yes (Mini) |
| Wi-Fi | No |
| HEOS Built-In | No |
| USB-B (USB DAC) | 1 (Rear) |
| PCM Sample Rate / Resolution | Up to 384kHz / 32-bit |
| DSD Audio Streaming | Up to 11.2MHz |
