Emotiva BasX A3+ 3.1 Channel Stereo Power Amplifier
- Regular price
- Rs. 114,500.00
- Sale price
- Rs. 114,500.00
- Regular price
-
Couldn't load pickup availability
Description
The Emotiva BasX A3+ is a powerful 3.1 channel stereo power amplifier designed to deliver clean, dynamic, and transparent sound with exceptionally low distortion. Utilizing Class A/B circuitry, it combines efficiency with linearity to ensure high-fidelity audio reproduction. The amplifier supports both balanced (XLR) and unbalanced (RCA) input options, providing flexible connectivity for various audio sources.
Its three-channel configuration makes it ideal for 3.1 home theater setups, delivering robust performance and high current to drive low-impedance speakers with clean and reliable power. Built-in protection mechanisms guard against thermal overload, overcurrent, and short-circuit conditions, ensuring safe and durable operation. Overall, the BasX A3+ offers audiophile-grade sound quality wrapped in a sturdy, compact chassis.
Technical Specifications
| Spec | Details |
|---|---|
| Brand | Emotiva |
| Model | BasX A3 plus |
| Color | Black |
| Power Output (All Channels Driven) | 140 watts RMS per channel; 20 Hz – 20 kHz; THD < 0.1%; into 8 Ohms200 watts RMS per channel; 1 kHz; THD < 1%; into 4 Ohms |
| Power Output (Two Channels Driven) | 150 watts RMS per channel; into 8 Ohms250 watts RMS per channel; into 4 Ohms |
| Power Bandwidth (Rated Power; 4-8 Ohms) | 20 Hz to 20 kHz (+/- 0.02 dB) |
| Broad Band Frequency Response | 10 Hz to 80 kHz +0/-1.8 dB |
| THD + Noise | < 0.02% (A-weighted); reference rated power |
| Signal to Noise Ratio (8 Ohm load) | > 112 dB; reference rated power (A-weighted) |
| Minimum Recommended Load Impedance (per channel) | 4 Ohms (one 4 Ohm load or two paralleled 8 Ohm loads) |
| Damping Factor (8 Ohm load) | > 500 |
| Input Sensitivity (for rated power; 8 Ohm load) | 1.25 |
| Input Impedance | 27 kOhms |
| Trigger Input | 5 – 12 V (AC or DC); <10 mA input current required |
| Trigger Output | 12 VDC; can drive load up to 120 mA |
| Power Requirements | 115 VAC or 230 VAC @ 50 / 60 Hz (auto detected) |
| Dimensions (W x H x D) | 17” wide x 4” high x 15-1/2” deep |
| Weight | 11.3 kg |
