Exceptional sound meets compact dimensions. The 4010A offers the same clarity, reliability and adaptability as its larger 4000 series family members – but in a tiny footprint.
Performance meets aesthetics
Manufactured in Finland using certified sustainable methods, the 4010A blends premium performance with beautiful aesthetics. Its recycled aluminium enclosure delivers superb directivity and reduces reflections, which combine with onboard room compensation switches to produce precise, intelligible sound quality in even the most challenging acoustic spaces.
Get more active
The active design of the 4000 series removes the need for bulky external power amplifiers, since the amplifiers, crossover filters and protection circuitry are contained within the speaker cabinet itself. This not only ensures that the electronics and drivers are mutually optimised, but also reduces the need for racks of external amplifiers and associated cabling. And thanks to our extensive range of mounting accessories, the 4000 series can be installed quickly and conveniently in almost any location.
Key Technologies
The speaker incorporates a range of advanced technologies designed to deliver accurate, controlled, and reliable audio performance. Active Crossovers provide precise frequency management, while Directivity Control Waveguide (DCW™) Technology ensures controlled and consistent sound dispersion. Intelligent Signal Sensing (ISS™) Technology enables efficient signal detection, and Minimum Diffraction Enclosure (MDE™) Technology helps minimise unwanted cabinet-related acoustic effects.
Optimised Amplifiers provide clean and efficient power delivery, while Protection Circuitry safeguards the speaker during demanding operation. Reflex Port Design enhances low-frequency performance, while Room Response Compensation allows the speaker to be optimised for its acoustic environment. Versatile Mountings provide flexible placement and installation options.
Technical Specifications
| Category | Spec |
|---|---|
| Frequency Response | 74 Hz – 20 kHz (±2.5 dB) |
| Low Cutoff (-6 dB) | 67 Hz |
| High Cutoff (-6 dB) | 25 kHz |
| Peak SPL | ≥105 dB (per pair at 1 m with music material) |
| Short-Term Max SPL | ≥96 dB |
| Long-Term Max SPL | ≥91 dB |
| Self-Generated Noise | ≤5 dB SPL |
| Weight | 1.5 kg (3.3 lb) |
| Height | 181 mm (7 1/8 in) |
| Width | 121 mm (4 3/4 in) |
| Depth | 115 mm (4 1/2 in) |
| Enclosure Material | Die-cast aluminium |
| Enclosure Type | Reflex port |
| Woofer Type | Cone |
| Woofer Diameter | 76 mm (3 in) |
| Tweeter Type | Metal dome |
| Tweeter Diameter | 19 mm (3/4 in) |
| Horizontal Directivity | Controlled horizontal directivity |
| Harmonic Distortion (70–400 Hz) | ≤3% |
| Harmonic Distortion (>400 Hz) | ≤0.5% |
| Bass Amplifier | 25 W Class D |
| Treble Amplifier | 25 W Class D |
| Total Amplification | 50 W Class D |
| Mains Voltage | 100–240 VAC, 50/60 Hz |
| Power Consumption – ISS Active | ≤0.5 W |
| Power Consumption – Idle | ≤5 W |
| Power Consumption – Full Output | 30 W |
| Audio Input | 10 kOhm balanced connector |
