The compact 4030C offers crystal clear sound and round-the-clock reliability, making it the natural choice for small to medium-sized commercial installations.
Precision and clarity
With beautiful aesthetics and 120 RAL colour finishes, the 4030C delivers Genelec’s trademark precision and clarity, with controlled directivity and the ability to adapt to challenging acoustic environments via simple rear panel room compensation switches. This ensures clean, intelligible, non-fatiguing audio whatever the playback level, plus bulletproof 24/7 reliability as standard. For indoor installations such clubs, bars, restaurants, boardrooms, museums and theatres, the 4030C is unsurpassed.
Get more active
The active design of the 4000 series removes the need for bulky external power amplifiers, since the amplifiers, crossover filters and protection circuitry are contained within the speaker cabinet itself. This not only ensures that the electronics and drivers are mutually optimised, but also reduces the need for racks of external amplifiers and associated cabling. And thanks to our extensive range of mounting accessories, the 4000 series can be installed quickly and conveniently in almost any location.
Key Technologies
The speaker incorporates a range of advanced Genelec technologies for accurate, powerful, and consistent audio performance. Active Crossovers provide precise frequency management, while Directivity Control Waveguide (DCW™) Technology ensures controlled sound dispersion. Intelligent Signal Sensing (ISS™) Technology enables efficient signal detection, and Minimum Diffraction Enclosure (MDE™) Technology helps minimise unwanted cabinet-related acoustic effects.
Optimised Amplifiers deliver clean and efficient power, while Protection Circuitry helps safeguard the speaker during demanding operation. Reflex Port Design enhances low-frequency performance, and Room Response Compensation allows the speaker to be optimised for its acoustic environment. Versatile Mountings provide flexible installation and placement options.
Technical Specifications
| Category | Spec |
|---|---|
| Frequency Response | 54 Hz – 20 kHz (±2 dB) |
| Low Cutoff (-6 dB) | 47 Hz |
| High Cutoff (-6 dB) | 25 kHz |
| Peak SPL | ≥110 dB (per pair at 1 m with music material) |
| Short-Term Max SPL | ≥104 dB |
| Long-Term Max SPL | ≥96 dB |
| Self-Generated Noise | ≤5 dB SPL |
| Weight | 4.9 kg (10.8 lb) |
| Height | 285 mm (11 1/4 in) |
| Width | 189 mm (7 1/2 in) |
| Depth | 178 mm (7 in) |
| Enclosure Material | Die-cast aluminium |
| Enclosure Type | Reflex port |
| Woofer Type | Cone |
| Woofer Diameter | 130 mm (5 1/8 in) |
| Tweeter Type | Metal dome |
| Tweeter Diameter | 19 mm (3/4 in) |
| Horizontal Directivity | Controlled horizontal directivity |
| Harmonic Distortion (50–100 Hz) | ≤2% |
| Harmonic Distortion (>100 Hz) | ≤0.5% |
| Bass Amplifier | 50 W Class D |
| Treble Amplifier | 50 W Class D |
| Total Amplification | 100 W Class D |
| Mains Voltage | 100–240 VAC, 50/60 Hz |
| Power Consumption – ISS Active | ≤0.5 W |
| Power Consumption – Idle | ≤3 W |
| Power Consumption – Full Output | 60 W |
| Audio Input | 10 kOhm balanced connector |
| Crossover Frequency | 3,000 Hz |
