When it comes to performance versus size, the 8020 has set the benchmark in nearfield monitoring for over 15 years.
Classic design
The 8020D is the latest revision of this enduring studio classic, boasting an even higher SPL yet lower energy consumption than previous versions. Designed to adapt to the broadest possible range of listening environments, the 8020D thrives when space is at a premium.
Transparent and truthful
Engineers love the transparent and truthful reproduction of the 8020D, and with its wide uncoloured sweet spot you are always in a position to make accurate, reliable mix decisions. Additionally, our Intelligent Signal Sensing (ISS™) circuitry detects when your monitor is no longer in use, placing it into an environmentally friendly, power-saving standby mode.
Technical Specifications
Category
Spec
Frequency Response
62 Hz – 20 kHz (± 2.5 dB)
Low Cutoff (-6 dB)
56 Hz
High Cutoff (-6 dB)
25 kHz
SPL Performance
Type
Spec
Peak SPL
≥107 dB (per pair, 1m, with music material)
Short Term Max SPL
≥100 dB (sine wave, 100 Hz–3 kHz, 1m)
Long Term Max SPL
≥93 dB (RMS, IEC noise, 1m)
Self-generated Noise
≤5 dB SPL (A-weighted, 1m)
Physical Characteristics
Attribute
Spec
Weight
3.2 kg (7.1 lb)
Height
230 mm (9 in)
Height with Iso-Pod
242 mm (9 1/2 in)
Width
148 mm (5 7/8 in)
Depth
142 mm (5 5/8 in)
Enclosure Material
Die cast aluminium
Enclosure Type
Reflex port
Drivers
Driver
Type
Diameter
Bass
Cone
105 mm (4 1/8 in)
Treble
Metal dome
19 mm (3/4 in)
Distortion Performance
Frequency Range
THD
50–200 Hz
≤3%
>200 Hz
≤0.5%
Amplifier Section
Component
Spec
Bass Amplifier
50 W Class D (8020D)
Treble Amplifier
50 W Class D (8020D)
Mains Voltage
100–240 VAC, 50/60 Hz
Power Consumption (ISS Active)
≤0.5 W
Idle Power Consumption
≤3 W
Full Output Power
60 W
Signal Processing
Component
Spec
Input Connector
XLR female, balanced, 10 kOhm
Crossover Frequency
3000 Hz
Product Variants
Product Code
Description
8020DPM
8020D Studio Monitor Dark Grey
8020DWM
8020D Studio Monitor White
—
8020D Studio Monitor Black
—
8020D Studio Monitor RAW
