If you love the compact format of the 8010 and 8020 models but demand higher SPL and more bass extension, meet the 8030C.
Welcome to the sweet spot
A consistent best-seller, the 8030C sits in the perfect sweet spot of big monitor performance and small footprint. It offers precise imaging and staggering detail, but can go louder and lower than its smaller siblings making it the perfect choice for slightly larger spaces.
Mixes that translate
The trademark rounded cabinet design of the 8030C delivers uncoloured reference performance both on and off axis, and rear panel room compensation switches let you optimise the 8030C for your individual room acoustics. All this helps you produce mixes that translate beautifully to other rooms and systems.
Technical Specifications
Category
Spec
Frequency Response
54 Hz – 20 kHz (±2 dB)
Low Cutoff (-6 dB)
47 Hz
High Cutoff (-6 dB)
25 kHz
SPL (Sound Pressure Level)
Peak SPL
≥110 dB – Max peak output per pair at 1 m with music material
Short Term Max SPL
≥104 dB – Max sine wave output (100 Hz to 3 kHz) at 1 m
Long Term Max SPL
≥96 dB – Max RMS output with IEC weighted noise at 1 m
Self-generated Noise
≤5 dB SPL – Free field, 1 m on axis (A-weighted)
Weight
5 kg (11.0 lb)
Dimensions
Component
Metric
Imperial
Height
285 mm
11 1/4 in
Height with Iso-Pod
299 mm
11 3/4 in
Width
189 mm
7 1/2 in
Depth
178 mm
7 in
Enclosure
Type
Details
Material
Die-cast aluminium
Type
Reflex port
Drivers
Type
Driver
Diameter
Bass
Cone
130 mm (5 1/8 in)
Treble
Metal dome
19 mm (3/4 in)
Directivity & Distortion
Category
Spe
Horizontal Directivity
Not specified
Harmonic Distortion
50–100 Hz: ≤2% >100 Hz: ≤0.5%
Amplifier Section
Component
Specification
Bass Amplifier
50 W Class D
Treble Amplifier
50 W Class D
Mains Voltage
100–240 VAC, 50/60 Hz
Power Consumption – ISS
≤0.5 W
Power Consumption – Idle
≤3 W
Power Consumption – Full
60 W
Signal Processing
Component
Specification
Input Connector
XLR female, balanced, 10 kOhm
Crossover Frequency
3000 Hz
Product Variants
Product Code
Description
8030CP
8030C Studio Monitor Dark Grey
8030CWM
8030C Studio Monitor White
-
8030C Studio Monitor Black
-
8030C Studio Monitor RAW
