Genelec 8320A SAM™ Studio Monitor
- Regular price
- Rs. 109,000.00
- Sale price
- Rs. 109,000.00
- Regular price
-
Couldn't load pickup availability
Description
Compact enough to fit into the tightest of spaces - yet intelligent enough to adapt to your recording environment - the 8320A is your entry point into the world of Smart Active Monitoring.
Transparent and truthful
The 8320A provides transparent and truthful reproduction, and with its wide uncoloured sweet spot you are always in a position to make accurate, reliable mix decisions. The recycled aluminium design of it rear-ported enclosure not only provides staggering LF extension from such a compact unit, its curved form and integrated waveguide guarantees precise, detailed performance both on and off axis.
Compact but clever
As a Smart Active Monitor, the 8320A integrates closely with our GLM software via which it can be configured and calibrated for your listening environment, compensating for detrimental room influences to create a truly optimised monitoring solution from mono to immersive. So whether you work in challenging acoustic spaces or need a mobile solution that can quickly adapt to different rooms, the 8320A is your compact but clever monitoring companion.
Technical Specifications
| Category | Specification |
|---|---|
| Frequency Response | |
| Flat Range (±1.5 dB) | 66 Hz – 20 kHz |
| Low Cutoff (-6 dB) | 55 Hz |
| High Cutoff (-6 dB) | 23 kHz |
| SPL (Sound Pressure Level) | |
| Peak SPL (per pair) | ≥107 dB (1 m, with music material) |
| Short-Term Max SPL | ≥100 dB (100 Hz – 3 kHz, 1 m, sine wave) |
| Long-Term Max SPL | ≥94 dB (RMS, IEC weighted noise, with protection) |
| Self-Generated Noise | ≤5 dB SPL (A-weighted, free field, on axis) |
| Weight | 3.2 kg (7.1 lb) |
| Dimensions | |
| Height | 230 mm (9 in) |
| Height with Iso-Pod | 242 mm (9 1/2 in) |
| Width | 151 mm (6 in) |
| Depth | 142 mm (5 5/8 in) |
| Enclosure | |
| Material | Die-cast aluminium |
| Type | Reflex port |
| Drivers | |
| Bass Driver | 105 mm (4 1/8 in) cone |
| Treble Driver | 19 mm (3/4 in) metal dome |
| Directivity | Vertical and Horizontal (not specified numerically) |
| Harmonic Distortion | 50–200 Hz ≤3%, >200 Hz ≤0.5% |
| Group Delay | 2.8 ms (Extended Phase Linearity OFF) |
| Amplifier Section | |
| Bass Amplifier | 50 W (Class D) |
| Treble Amplifier | 50 W (Class D) |
| Power Consumption | |
| ISS Active | ≤0.5 W |
| Idle | ≤3 W |
| Full Output | 50 W |
| Signal Processing | |
| Inputs | 1 x XLR female, balanced (10 kΩ) |
| Control Ports | 2 x RJ45 (CAT5) GLM network connectors |
Up to 10 Years of Hassle-Free Warranty.
Many sellers offer products without service, but we’ve got you covered. Contact us to book your warranty, drop it in-store, or ship it to us for a refund or exchange for up to 10 years.
