For audio professionals using Audio-over-IP (AoIP) connectivity, the Genelec 9401A System Management Device enables the smooth integration of Smart Active Monitors and Subwoofers (SAM™) into SAM system layouts, from stereo to immersive, using ST2110, AES67 and Ravenna streams as the source while offering full support for room adaption from our powerful Genelec Loudspeaker Manager (GLM™) software.
Smart Active Monitoring (SAM™) and GLM™ Calibration Technology
Genelec’s Smart Active Monitoring (SAM™) technology ensures accurate, consistent sound reproduction in any acoustic environment. Integrated into all SAM monitors and subwoofers, this intelligent system works in conjunction with GLM™ (Genelec Loudspeaker Manager) software to automatically calibrate each speaker based on room acoustics, speaker placement, and listener position. Using the included calibration microphone and network adapter, GLM measures the acoustic response of the room and optimizes each monitor’s performance to deliver the most precise and neutral monitoring environment possible. This makes SAM systems ideal for critical mixing, mastering, and immersive audio work, where translation and accuracy are essential.
Audio-over-IP Integration with Genelec 9401A
Audio-over-IP (AoIP) technology allows high-quality, uncompressed audio to be transmitted over standard IP networks, supporting modern workflows in broadcast, post-production, and immersive audio setups. The Genelec 9401A AoIP Monitoring Interface bridges this technology with Genelec’s SAM ecosystem by converting AoIP audio streams (including ST2110, AES67, and Ravenna) into AES/EBU outputs. It delivers 16 digital audio channels via a DB25 connector, which can be seamlessly integrated into a SAM monitoring system.
The 9401A also features a dedicated subwoofer output and flexible auxiliary stereo monitoring output, making it highly adaptable for various studio configurations. One 9401A can support immersive formats such as 9.1.6, while multiple units can be combined to handle larger channel counts, including 22.2 setups. Compatible with all Genelec SAM monitors and subwoofers except the 8320A the 9401A also supports the UNIO platform, enabling precise alignment between speaker-based and personal headphone monitoring workflows.
Technical Specifications
| Spec | Details |
|---|---|
| Supported Sampling Rates | 44.1 – 192 kHz |
| Bit Depths Supported | 16-bit, 24-bit, or 32-bit per sample |
| Output Sampling Rate | Follows input sampling rate (synchronous) |
| AES Output Connector | DB25 with AES59-2012 standard pinout |
| Power Supply | Universal input: 100–240 VAC (IEC connector) |
| Power Consumption | 12 W during normal operation < 4.5 W in ISS (power saving) mode |
| Form Factor | 1U rack-mountable enclosure |
