JVC DLA-NZ7B Home Theater Projector 8K/60p/4K120p Input

Description

JVC DLA NZ7B DLA-NZ7 D-ILA Projector World First Home Theater Projector to Feature 8K/60p/4K120p Input

The DLA-NZ7 D-ILA projector is the world first home theater projector to feature 8K/60p/4K120p input. It is equipped with a new 8K/e-shift proprietary technology to reproduce 8K-quality images. The projector is driven by three native 4K D-ILA devices, high-quality 65 mm glass lens, and Ultra-High Brightness of 2,200 lumens. The BLU-Escent laser diode light source also contributes to project images that come close to reality. Compatible with the latest HDR10+, the projector boasts industry leading HDR performance. 8K, Laser, and HDR are the keywords that describe JVC's DLA-NZ7.

Frame Adapt HDR Generation 2

The Frame Adapt HDR technology, which uses a proprietary algorithm to instantaneously analyze the maximum brightness of HDR10 content per frame and adjust the dynamic range in real time to the optimum range for video projection on projectors, has evolved into the second generation.

As the culmination of the HDR image processing technology that we have cultivated up to now, we have completely reexamined the tone mapping algorithm in accordance with the scene and frame, and have achieved HDR images with higher definition and full of three-dimensional feeling by suppressing the whiteness especially in the high brightness area.

Light Source Control by Gauge

Laser light source adjustment function that can be finely adjusted according to the environment and preference. After the update from the previous 3 steps, fine adjustment of 0 -100 steps is possible, and adjustment based on the brightness on the screen and flexible setting according to the use environment are possible.

USB Back-up

USB backup function that can save and write all settings at once.

This function saves the settings on the main unit menu to a commercially available USB flash drive. Professional adjustments can be saved or backed up in advance to undo unintended adjustments by children or family members.

World’s First Home Projector Capable Of

• inputting 8K60p/4K120p signals
• These projectors adopt LSI's developed with the latest technology to process the vast amount of 8K input data, and an up converter to bring any source up to high definition 8K resolution. As a result, more beautiful and realistic video images full of contrast and reality can be enjoyed regardless of the source, from video streaming to 4K UHD-BD videos.
• 4K120p input ideal for Low Latency Mode

Because these projectors are equipped with 4K120p input, signal latency is infinitesimal, making it effective when displaying high frame-rate gaming content on large screens. What’s more, Low Latency Mode reduces delay in displaying PC signals and games, and improves response to the users’ rapid operations.

Features

• 8K/e-shift technology reproduces 8K image quality
• BLU-Escent Laser Light Source
• High brightness of 2,200 lm provides vibrant and dynamic images
• Native Contrast Ratio of 40,000:1 translates to a spectacular Dynamic Contrast Ratio of ∞ :1
• 2x HDMI (48 Gbps, HDCP 2.3) inputs, supporting 8K60P and 4K120P input signals
• HDR10+ contains the metadata of the producer’s intentions for each scene, and with such data, the projector is able to automatically reproduce images as the creator intended.
• Frame Adapt HDR dynamically tone maps any HDR10 content frame-by-frame or scene-by-scene and automatically performs adjustment to achieve optimal images close to reality as seen by human eyes. As a part the Frame Adapt HDR, the projector offers improved gamma processing accuracy from 12- to 18-bit equivalent to reproduce smoother and finer gradation. Additional Frame Adapt HDR picture modes allows for optimum playback with the widest variety of lighting conditions or theater environments.
• Theater Optimizer function, which works in Frame Adapt HDR mode, offers optimum HDR images by analyzing usage environments using the screen size and gain information and intelligently adjusts tone mapping. HDR Quantizer with New Auto (Wide) level mode provides brighter/more dynamic HDR images.
  Auto Tone Mapping function automatically adjusts settings for optimum HDR10 image quality.
• New FILMMAKER MODE™ that faithfully recreates the creator’s intentions
  New 0.69-inch 4K D-ILA (4096 x 2160) device x 3 17-element, 15-group all-glass 65mm diameter high-quality lens
  For easy reproduction, the projector switches automatically to HDR picture mode when HDR10 signals are received.
• Clear Motion Drive supporting 4K60P (4:4:4) signal improves moving images more than ever ISF C3 (Certified Calibration Controls) mode to reproduce excellent picture quality optimized for specific environments
• Eight settings of Installation Mode include Lens Control, Pixel Adjustment, Mask, Anamorphic on or off, Screen Adjust, Installation Style, Keystone, and Aspect; stored installation modes for various environments can be called up.
• Color Management System with 6-axis Matrix
• Auto-Calibration Function using an optical sensor.
• Low Latency Mode suppresses display delay for faster response when receiving signals from PC and game consoles
• Wireless transmission options for 3D viewing

Technical Specifications

Device

Light Source


HDR

Lens

HDMI

Connections

3D

Picture Settings

Power & Environment

Dimensions & Weight
