Linn Klimax DS Organik DAC Upgrade
The Linn Klimax DS Organik DAC upgrade focuses exclusively on the digital source player (DS), without the preamplifier circuitry, volume control, analogue inputs or video connections found in the DSM variants.
Organik Upgrade Package for Klimax DS
The streaming engine upgrade replaces the internal digital architecture with an ARM-Linux computing platform. It enables native high-resolution playback, supporting PCM files up to 24-bit/384kHz and native DSD256 processing. The upgrade also integrates native Apple AirPlay 2 connectivity into the existing chassis.
Features Excluded from the DS Upgrade
Because the hardware is specifically engineered for the standalone Klimax DS architecture, this upgrade excludes features reserved exclusively for the Klimax DSM models.
Features
The Linn Klimax DS Organik Upgrade supports a range of music streaming and playback options, including Tidal, Qobuz, Calm Radio, Spotify Connect, Roon, Deezer, Amazon Music and Presto Music. It also includes AirPlay and AirPlay 2 connectivity options. Additional solutions are available for services and features such as Spotify Lossless, Chromecast and Tidal Connect through compatible external devices.
Zero Preamplifier I/O
The upgrade does not include analogue input stages, ADC processing or switchable analogue volume outputs.
No Video/Digital Routing
HDMI switching, optical digital ports and USB audio inputs are not included.
Physical Control Constraints
The upgrade does not add a front-panel volume dial, glass smart-buttons or proximity sensors.
Network Backbone
The system relies on a high-speed Gigabit Ethernet connection and does not add onboard Wi-Fi or Bluetooth.
Technical Specifications
|
Category |
Specification |
Details |
|---|---|---|
|
Product Name |
Model |
Klimax DS Organik Upgrade |
|
Product Type |
Description |
ARM Linux digital music player |
|
Dimensions |
Height |
60 mm (2.3 inches) |
|
Dimensions |
Width |
350 mm (15 inches) |
|
Dimensions |
Depth |
355 mm (14.2 inches) |
|
Weight |
Net Weight |
10 kg / 22 lb |
|
Mains Supply |
Voltage |
Auto-ranging: 100–120 V AC (±10%), 50–60 Hz; 200–240 V AC (±10%), 50–60 Hz |
|
Power Consumption |
Rated |
13 W |
|
Supported File Types |
Formats |
FLAC, WAV, MP3, AAC, AIFF/AIFC, ALAC, OGG/Vorbis, WMA, DSD (DSF and DFF) |
|
Audio Sample Rates |
Supported |
7.35, 8, 11.025, 12, 14.7, 16, 22.05, 24, 29.4, 32, 44.1, 48, 88.2, 96, 176.4, 192 and 384 kHz |
|
Word Depths |
Supported |
16–24 bits |
|
Control Protocol |
Compatibility |
UPnP media servers and UPnP AV 1.0 control points |
|
Sources |
Supported |
LAN, Internet radio, TIDAL, Qobuz, Calm Radio, Spotify Connect, NetAux, Amazon Music, Presto Music |
|
Ethernet |
Connection |
100Base-T RJ45 |
|
Local Proxy Control |
Connections |
2 × RS232 |
|
Exakt Link |
Connections |
2 × RJ45 (CAT-5a) |
|
Analogue Output |
Stereo RCA |
2 Vrms |
|
Output Impedance |
RCA |
150 Ω |
|
RCA Output Coupling |
Type |
Transformer |
|
Analogue Output |
Stereo Balanced XLR |
4 Vrms |
|
Output Impedance |
XLR |
300 Ω |
|
XLR Output Coupling |
Type |
Direct |
