Powersoft
Powersoft Duecanali 804 DSP+
- Regular price
- Rs. 178,245.00
- Sale price
- Rs. 178,245.00
- Regular price
-
Get free shipping on your order.
1 In Stock
Couldn't load pickup availability
Description
DUECANALI 804 DSP+ 800W/2-channel Flexible Amplifier with DSP and AES67
The ability to implement any configuration with ease makes the Duecanali series extremely flexible. Powersoft’s legendary efficiency saves valuable energy, keeping both operational cost and ‘carbon footprint’ at a minimum. The Duecanali 804 DSP+ is designed to work with Lo-Z (from 2 Ω ) and with 70V/100V distributed lines: any mixed impedance output loads can be realised.
A fully integrated state-of-the-art DSP yields extensive system management functionality. In addition to sound shaping and limiter functions in a unique Powersoft style, the DSP hardware and ArmoníaPlus software enable compliance with IEC 60849 for the crucial requirements of sound systems for emergency purposes.
DSP+ versions extend signal routing capabilities with the integration of AES67 digital audio networking architecture. MyPowersoft services are available for this product.
Features
| Category | Specification |
|---|---|
| Power Supply | Universal, regulated switch mode with PFC (Power Factor Correction) |
| Tolerant up to 400VAC | |
| Patented output filter with ripple cancellation network | |
| Low Inrush Limiting reduces AC inrush current, no need for expensive power sequencers | |
| Detachable AC mains cable with IEC C19/22.2 (16A for EU, 20A for USA) socket | |
| Protections | AC Protection: Shuts down power supply if AC voltage is outside the operating range |
| Clip Limiter: Prevents severely clipped waveforms from reaching loudspeakers while maintaining full peak power output | |
| DC Protection: Protects against infrasonic signal at the outputs | |
| VHF Protection: Protects loudspeakers from non-audible, strong, non-musical high-frequency signals | |
| Short Circuit Protection: Automatic reset protection for output circuits | |
| Long Term Limiter: Reduces maximum output for steady long-term RMS signals | |
| Thermal Protection: Output stages operating temperature up to 80°C (176°F) | |
| Fan: Temperature-controlled, continuous variable speed fan (front-to-back airflow) | |
| Temperature Forecast: LCD traced historical behavior | |
| General Specifications | Fixed frequency switch-mode output stage for high sound accuracy |
| Compact size: 1 RU for reduced rack cost and space | |
| Lightweight: 7 kg (15.4 lbs) for easier racking and shipping | |
| Standard Phoenix connectors: analog audio outputs, aux supply, alarms, GPIO | |
| Remotely switchable double input (main and aux) per channel | |
| Loudspeaker System Configuration | Direct drive for low impedance loads or 70V/100V Hi-Z distributed lines |
| Switchable 35Hz / 70Hz high pass filter per channel | |
| Mixed configuration with Lo-Z/Hi-Z systems possible | |
| Bridged mode low impedance per channel pair | |
| Alarms and GPI/O | NC/NO contacts per channel for alarm notifications |
| Remote ON/OFF switch | |
| Remote VCA control per channel | |
| Digital Signal Processing | TI C6000 DSP platform |
| Dual 24-bit AD/DA converter @ 48 kHz, Tandem® architecture | |
| Independent equalizers per channel providing PEQ, raised cosine, shelving IIR filters, and custom output FIR filters | |
| Delay up to 100 ms for time alignment | |
| Active DampingControl™ for cable compensation | |
| Peak, RMS voltage, RMS current, TruePower™ limiters | |
| Remote Control & Monitoring | Software : Control and diagnostics via ArmoníaPlus, Dedicated WebApp |
| Hardware : Attenuation from 0dB to 26dB, High-pass filters (35Hz, 70Hz), Lo-Z/Hi-Z/70V/100V output selection, Adjustable gain (26dB to 35dB) |
Specifications
| General | |||
| Output power per Channel | |||
| Output power per Channel | 500 W @ 2 Ω | 400 W @ 4 Ω | 400 W @ 8 Ω |
| Bridge mode | 1000 W @ 4 Ω | 800 W @ 8 Ω | |
| Max output voltage / current | |||
| Max unclipped output voltage@8 Ω | 80 Vpeak | ||
| Current | 39 Apeak | ||
| AC main power | |||
| Power supply | Universal, regulated switch mode with PFC (Power Factor Correction) | ||
| Nominal power requirement | 100-240 V ±10%, 50-60 Hz | ||
| Operating voltage | 90 V – 264 V | ||
| Power consumption / Current Draw | |||
| Idle | 115 V: 23.0 W – 0.34 A | 230 V: 22.5 W – 0.21 A | |
| 1/8 of max output power @ 4 Ω | 115 V: 148 W – 1.4 A | 230 V: 147 W – 0.9 A | |
| THERMAL | |||
| Operating temperature range | 0° – 45° C – 32° – 113° F | ||
| Thermal dissipation | |||
| Idle | 115 V: 78 BTU/h | 230 V: 77 BTU/h | |
| 1/8 of max output power @ 4 Ω | 115 V: 162 BTU/h | 230 V: 161 BTU/h | |
