Powersoft Mezzo 322 A+
- Regular price
- Rs. 96,140.00
- Sale price
- Rs. 96,140.00
- Regular price
-
Couldn't load pickup availability
Description
320W/2-channel Compact Amplifier with DSP and AES67
Mezzo 322 A+ heralds the same levels of reliability, build quality, and acoustic proprieties of any Powersoft amplifier platform, in half the size. Exceedingly flexible, “A+” versions of Mezzo offer all the remote control and monitoring functions of the “A” versions, further extending networking capabilities with AES67. The small form factor allows it to be mounted anywhere thanks to the included mounting kit. The 320 W versions of Mezzo can also be mounted in air handling spaces, such as ceilings or wall boxes. Two-channel versions of Mezzo also feature 2 line-level outputs, further extending routing options.
Features
| Feature | Description |
|---|---|
| Multiple Mounting Options | Flexible installation in any rack or surface |
| Auto-Setup | Quick and automatic configuration for easy deployment |
| Power-Sharing | Intelligent allocation of power across channels |
| Full Remote Control | Integration with third-party control systems (via network) |
Specifications
| Category | Details |
|---|---|
| Output Power per Channel | 160 W @ 2 Ω / 160 W @ 4 Ω / 160 W @ 8 Ω |
| Max Power-Sharing per Channel | 320 W @ 4 Ω / 320 W @ 8 Ω |
| Max Output Voltage | 142 Vpeak |
| Max Output Current | 15.6 Apeak |
AC Main Power
| Parameter | Value |
|---|---|
| Power Supply | Universal, regulated switch mode with PFC |
| Nominal Power | 100-240 V ±10%, 50-60 Hz |
| Operating Voltage | 90 V – 264 V |
Power Consumption / Current Draw
| Condition | 115 V | 230 V |
|---|---|---|
| Idle | 12 W – 0.23 A | 13 W – 0.20 A |
| 1/8 Max Output @ 4 Ω | 73 W – 0.68 A | 77 W – 0.44 A |
Thermal Dissipation
| Condition | 115 V | 230 V |
|---|---|---|
| Idle | 41 BTU/h | 46 BTU/h |
| 1/8 Max Output @ 4 Ω | 81 BTU/h | 97 BTU/h |
Up to 10 Years of Hassle-Free Warranty.
Many sellers offer products without service, but we’ve got you covered. Contact us to book your warranty, drop it in-store, or ship it to us for a refund or exchange for up to 10 years.
