Mezzo 322 A heralds the same levels of reliability, build quality, and acoustic proprieties of any Powersoft amplifier platform, in half the size. Ultimately flexible, "A" versions of Mezzo offer remote control and monitoring of all the vital functions. The small form factor allows it to be mounted anywhere thanks to the included mounting kit, the 320 W versions of Mezzo can also be mounted in air handling spaces, such as double ceilings or wall boxes. Two channel versions of Mezzo also feature 2 line level outputs, fourthly extending routing options.
Features
| Feature |
Description |
| Multiple Mounting Options |
Supports half-rack, full-rack, or surface mounting configurations. |
| Auto-Setup |
Enables automatic configuration for plug-and-play deployment. |
| Power-Sharing |
Allows dynamic distribution of available power across output channels. |
| 3rd Party Remote Control |
Fully compatible with external control platforms like Crestron and Q-SYS. |
Technical Specifications
General Spec
| Category |
Specification |
| Output Power per Channel |
160 W @ 2 Ω / 160 W @ 4 Ω / 160 W @ 8 Ω |
| Power-Sharing Capacity |
320 W per channel @ 4 Ω / 8 Ω |
| Max Unclipped Output Voltage |
142 Vpeak |
| Max Output Current |
15.6 Apeak |
AC Main Power
| Parameter |
Value |
| Power Supply |
Universal, regulated switch mode with PFC |
| Nominal Requirement |
100–240 V ±10%, 50–60 Hz |
| Operating Voltage Range |
90 V – 264 V |
Power Consumption / Current Draw
| Mode |
115 V |
230 V |
| Idle |
11 W – 0.21 A |
12 W – 0.17 A |
| 1/8 Max Output Power @ 4 Ω |
73 W – 0.67 A |
75 W – 0.41 A |
Thermal Dissipation
| Mode |
115 V |
230 V |
| Idle |
38 BTU/h |
40 BTU/h |
| 1/8 Max Output Power @ 4 Ω |
78 BTU/h |
91 BTU/h |
