Powersoft Ottocanali 8K4 DSP+D 8000W/8-channel Flexible Amplifier with DSP and Dante™
- Regular price
- Rs. 596,030.00
- Sale price
- Rs. 596,030.00
- Regular price
-
Couldn't load pickup availability
Description
The Ottocanali 8K4 DSP+D is a flexible and reliable 8-channel power amplifier with up to a total of 8,000 W at 4Ω, ideal for multi-zone applications in medium to large-scale installs: Ottocanali 8K4 DSP+D supports any combination of lo-Z loudspeakers, mono-bridgeable channel pairs and 70V/100V Hi-Z distributed lines with no need for output step-up transformers. The Ottocanali 8K4 DSP+D features switchable main/aux signal inputs and offers a wide range of system control, alarms, GPI/O and monitoring functions as well as sound shaping options.
The Ottocanali 8K4 DSP+D implements universal switch mode power supplies with PFC and patented SRM (Smart Rails Management) technology maximising reliability & efficiency and reducing power consumption.
New Ottocanali 8K4 DSP+D heralds new and innovative level of signal processing. Providing flexible routing and mixing, multi-stage equalisation with raised-cosine, IIR and FIR filters, delay up to 2 s in input processing and 100 ms for time alignment, gain and polarity adjustment, crossover, peak limiters, TruePower™ limiters and Active DampingControl™.
Powersoft’s legendary efficiency saves valuable energy, keeping both operational cost and ‘carbon footprint’ at a minimum: the Ottocanali 8K4 DSP+D shines with outstandingly low power consumption and heat dissipation. This dramatically reduces costs from the AC mains supply and air conditioning/cooling systems not to mention the benefits to the environment for a greener planet. MyPowersoft services are available for this product.
Technical Specifications
Power Supply
| Feature | Details |
|---|---|
| Power Supply | Universal switch mode power supply up to 400VAC tolerant with Power Factor Correction |
| Output Filter | Patented output filter with ripple cancellation network |
| Inrush Limiting | Low Inrush Limiting reduces AC inrush current, eliminating the need for expensive power sequencers |
| Detachable AC Mains Cable | IEC C19/22.2 (16A for EU, 20A for USA) socket |
Protections
| Protection Type | Details |
|---|---|
| AC Protection | Shuts down power supply when AC mains voltage is outside operating range |
| Clip Limiter | Prevents severely clipped waveforms from reaching loudspeakers while maintaining full peak power output |
| DC Protection | Protects against infrasonic signal at the outputs |
| VHF Protection | Protects loudspeakers against non-audible, strong, non-musical high-frequency signals |
| Short Circuit Protection | Protects the amplifier from short circuits or stressful events with automatic protection reset |
| Long Term Limiter | Protects loudspeakers against steady long-term RMS (non-audio) signals by reducing maximum output |
| Thermal Protection | Output stages operating temperature up to 80°C (176°F) |
| Cooling Fan | Temperature-controlled continuous variable speed fan with front-to-back airflow |
General Specifications
| Feature | Details |
|---|---|
| Switch Mode Output Stage | Fixed frequency switch mode output stage for high-grade sound accuracy |
| Rack Size | All models 2 RU for reduced rack cost and space |
| Weight | Lightweight – 14 kg / 30.8 lbs for easier racking and shipping |
| Connectors | Standard Phoenix connectors: analog and digital input, audio outputs, aux supply, alarms, and GPIO |
| Input Switching | Remotely switchable double input |
| Loudspeaker System Configuration | Direct drive of low impedance loads or 70V / 100V Hi-Z distributed lines |
| High Pass Filter | Switchable 35Hz / 70Hz high pass filter per channel |
| Mixed Configuration | Mixed configuration with Lo-Z/Hi-Z systems possible |
| Bridged Mode | Bridged mode with low impedance per channel pair |
Digital Signal Processing (DSP)
| Feature | Details |
|---|---|
| DSP Architecture | TI C6000 DSP platform architecture |
| AD/DA Converter | Dual 24bit @ 96 kHz Tandem® architecture, 127 dB dynamic range, per channel |
| Equalizers | Input/output independent equalizers per channel: Raised-cosine, custom FIR, parametric IIR (peaking, hi/lo-shelving, all-pass, band-pass, band-stop, hi/lo-pass) |
| Crossovers | Linear phase (FIR), hybrid (FIR-IIR), Butterworth, Linkwitz-Riley, Bessel: 6 dB/oct to 48 dB/oct (IIR) |
| Delay | Input delay up to 2s and output delay up to 100ms for time alignment per channel |
| Cable Compensation | Active DampingControl™ for cable compensation |
| Power Limiter | TruePower™ RMS voltage, RMS current + Peak Limiter |
Alarms and GPIO
| Feature | Details |
|---|---|
| Alarm Contacts | NC/NO contacts per channel for alarm notifications |
| Input Switch | Remote AUX/MAIN inputs switch |
| Remote On/Off Switch | Remote ON/OFF switch |
| PWS OUT Connector | Provides 24VDC |
Remote Management
| Feature | Details |
|---|---|
| Control and Monitoring | Through ArmoníaPlus |
