Powersoft Quattrocanali 2404 DSP
- Regular price
- Rs. 267,140.00
- Sale price
- Rs. 267,140.00
- Regular price
-
Get free shipping on your order.
2 In Stock
Couldn't load pickup availability
Description
QUATTROCANALI 2404 DSP 2400W/4-channel Flexible Amplifier
Quattrocanali 2404 offers the traditionally amazing sound quality and reliability of all Powersoft products.The patented SRM (Smart Rails Management) technology allows to maximize the efficiency of the system and drastically reduce power consumption in any load and usage condition. Quattrocanali features the lowest thermal dissipation in the industry, reducing the need for external cooling devices.
Quattrocanali is designed to operate with Lo-Z (from 2 Ω) and 70V/100V distributed lines or any mix of the two.DSP+D versions of the Quattrocanali grant in-depth control and monitoring via Armonìa, tailoring the sound and managing the system can be done by a remote, decentralised location.
This Amplifier Platform can also be trusted in mission-critical applications, such as fire alarm systems, thanks to the cleverly engineered power supply that allows reliable operation even when connected to a UPS. MyPowersoft services are available for this product.
Features
Power Supply
| Feature | Description |
|---|---|
| Patented Output Filter with Ripple Cancellation | Designed to reduce unwanted ripple, ensuring high-quality audio output. |
| Low Inrush Limiting | Reduces AC inrush current during startup, eliminating the need for power sequencers. |
| Detachable AC Mains Cable | Comes with an IEC C19/22.2 socket (16A for EU, 20A for USA) for easy connections. |
Protections
| Feature | Description |
|---|---|
| AC Protection | Automatically shuts down the power supply when AC mains voltage is outside the operating range. |
| Clip Limiter | Prevents severely clipped waveforms from reaching loudspeakers, maintaining full peak power output. |
| DC Protection | Protects against infrasonic signals reaching the outputs. |
| VHF Protection | Protects loudspeakers from high-frequency signals that are not audible but potentially harmful. |
| Short Circuit Protection | Protects the amplifier from short circuits or other damaging events, with an automatic reset feature. |
| Long Term Limiter | Reduces maximum output to protect speakers against steady long-term RMS (non-audio) signals. |
| Thermal Protection | Protects the output stages from overheating (up to 80°C or 176°F). |
| Temperature Controlled Fan | Continuous variable speed fan with front-to-back airflow for efficient cooling. |
| Temperature Forecast | Displays historical temperature data on an LCD, forecasting potential thermal issues. |
General Features
| Feature | Description |
|---|---|
| Fixed Frequency Switch-Mode Output Stage | Delivers high-grade sound accuracy for optimal audio performance. |
| Compact Size (1 RU) | Reduced rack cost and space, with all models fitting into a 1RU form factor. |
| Light Weight (7 kg / 15.4 lbs) | Easier to rack and ship, minimising logistical challenges. |
| Phoenix Connectors | Standard analog audio outputs, auxiliary supply, alarms, and GPIO connections. |
| Remotely Switchable Double Input | Main and auxiliary inputs can be remotely switched per channel. |
Settings
| Feature | Description |
|---|---|
| Built-in Defeatable Clip Limiters | Adjustable clip limiters for each channel to prevent distortion. |
| Digital Gain-Attenuator Control | Provides precise control over gain and attenuation levels. |
| Defeatable Gate Selection | Users can select or disable gates for each channel. |
| User Selectable Gain/Sensitivity | Choose the desired gain or sensitivity settings for each channel. |
| User Selectable Max Output Power | Set the maximum output power for each channel. |
| User Selectable Max Mains Current Draw | Control the maximum current drawn from the mains. |
| Lockable Setup with Access Key Code | Secures settings with a user-selectable access key for preventing unwanted changes. |
| RS-485 Remote Control Interface | Full diagnostics, operational settings, and system monitoring via remote control. |
Digital Signal Processing (DSP)
| Feature | Description |
|---|---|
| TI C6000 DSP Platform | High-performance DSP platform for advanced signal processing. |
| Dual 24-bit @ 48 kHz AD/DA Converters | Utilizes Tandem® architecture for high-quality audio conversion. |
| Independent Equalizers Per Channel | Provides PEQ, raised cosine, shelving IIR filters, and custom output FIR filters for each channel. |
| Delay up to 100 ms | For precise time alignment of audio signals. |
| Active DampingControl™ | Compensates for cable loss, ensuring consistent sound quality. |
| Peak, RMS Voltage, RMS Current Limiters | TruePower™ limiters to prevent damage to equipment and ensure optimal performance. |
Remote Control and Monitoring
| Control via Software | Description |
|---|---|
| ArmoniaPlus Software | Comprehensive control and diagnostics software for real-time monitoring and adjustments. |
| Dedicated WebApp | Access system status, monitoring, and diagnostics through a web interface. |
| Control via Hardware | Description |
|---|---|
| Attenuation Control (0dB to 26dB) | Precise control over attenuation levels for each channel. |
| High-Pass Filters (35Hz, 70Hz) | Selectable high-pass filters to shape frequency response as needed. |
| Lo-Z/Hi-Z/70V/100V Output Selection | Choose the appropriate output mode for different speaker configurations. |
| Adjustable Gain (26dB to 35dB) | Fine-tune gain settings for optimal output levels. |
Specifications
General
| Parameter | Specification |
|---|---|
| Output Power per Channel | 800 W @ 2 Ω, 600 W @ 4 Ω, 600 W @ 8 Ω |
| Bridge Mode | 1600 W @ 4 Ω, 1200 W @ 8 Ω |
| Max Output Voltage / Current | Max Unclipped Voltage @ 8 Ω: 100 Vpeak |
| Max Current Output Voltage | Current: 45 Apeak |
| AC Main Power | Universal, regulated switch mode with PFC (Power Factor Correction) |
| Nominal Power Requirement | 100-240 V ±10%, 50-60 Hz |
| Operating Voltage | 90 V – 264 V |
Power Consumption / Current Draw
| Condition | 115 V | 230 V |
|---|---|---|
| Idle Power Consumption | 31 W – 0.45 A | 31.8 W – 0.26 A |
| 1/8 of Max Output Power @ 4 Ω | 406 W – 2.1 A | 438 W – 2.39 A |
Thermal Specifications
| Condition | 115 V | 230 V |
|---|---|---|
| Operating Temperature Range | 0° – 45° C (32° – 113° F) | |
| Thermal Dissipation | ||
| Idle | 107 BTU/h | 109 BTU/h |
| 1/8 of Max Output Power @ 4 Ω | 361 BTU/h | 361 BTU/h |
