Rotel A12MKII Integrated Amplifier
- Regular price
- Rs. 128,900.00
- Sale price
- Rs. 128,900.00
- Regular price
-
Couldn't load pickup availability
Description
A12MKII
The A12MKII stands well above its sleek design delivering 60 Watts of dynamic Class AB output into 8 ohms. This integrated amplifier supports your favorite sources including MM Phono Stage, analog, digital, PC-USB and wireless Bluetooth. Optimized circuits and a 32-bit DAC deliver spacious and open reproduction of the music.
The A12MKII Integrated Amplifier stands well above its slim, sleek design profile designed and engineered for music lovers. Powered by Rotel’s oversized in-house manufactured toroidal transformer the A12MKII delivers 60 Watts of clean, dynamic Class AB output power into 8 ohms. A Moving Magnet Phono Stage, 4 RCA analog, 4 digital, PC-USB and high quality wireless aptXTM Bluetooth input ensures connection to your favorite sources. The premium 32-bit Texas Instruments DAC extracts genuine and accurate details of the music with optimized circuits preserving the integrity of the audio stream. Slim and powerful the A12MKII delivers on Rotel’s iconic brand heritage.
Technical Specifications
| Spec | Value |
|---|---|
| Dimensions (W × H × D) | 430 × 93 × 345 mm (17" × 3.6" × 13.5") |
| Front Panel Height | 80mm (3.15") |
| Power Requirements | 120V, 60Hz |
| Power Consumption | 230W |
| Standby Power Consumption | <0.5W |
| Net Weight | 8.76 kg (19.31 lbs.) |
| BTU Rating (4Ω, 1/8th power) | 632 BTU/h |
| Maximum Power Output | 120W/Ch (4Ω) |
| Continuous Power Output | 60W/Ch (8Ω) |
| Total Harmonic Distortion (THD) | <0.018% |
| Frequency Response | Line Level Inputs: 10Hz - 100kHz, ±0.5dB, Digital Inputs: 10Hz - 90kHz, ±2dB, Phono Input: 20Hz - 20kHz, ±0.5dB |
| S/N Ratio (IHF "A" Weighted) | Line Level Inputs: 100dB, Digital Inputs: 103dB, Phono Input: 90dB |
| Intermodulation Distortion (60Hz:7kHz, 4:1) | <0.03% |
| Damping Factor | 220 |
| Input Sensitivity | Line Level Inputs: 230mV, Digital Inputs: 0dBfs, Phono Input (MM): 3.4mV |
| Input Impedance | Line Level Inputs: 24kΩ, Digital Inputs: 75Ω, Phono Input (MM): 47kΩ |
| Input Overload | Line Level Inputs: 4V, Phono Input: 50mV |
| Preout Level | 1.2V |
| Output Impedance | 470Ω |
| Tone Controls | ±10dB at 100Hz / 10kHz |
| Digital Input | SPDIF LPCM (Up to 24-bit/192kHz) |
| PC-USB | USB Audio Class 1 (up to 24-bit/96kHz), USB Audio Class 2 (up to 32-bit/384kHz) *Driver installation required |
| Roon Tested | Yes |
Up to 10 Years of Hassle-Free Warranty.
Many sellers offer products without service, but we’ve got you covered. Contact us to book your warranty, drop it in-store, or ship it to us for a refund or exchange for up to 10 years.
