Rotel DX-3 Headphone Amplifier
- Regular price
- Rs. 179,900.00
- Sale price
- Rs. 179,900.00
- Regular price
-
Couldn't load pickup availability
Description
DX-3
The ultimate Personal Audio companion packaged in exquisite industrial design with the sophistication of a premium, fully balanced Headphone Amplifier. The ESS Sabre ES9028PRO DAC renders music via PC-USB input (32-bit/384kHz), Coaxial/Optical (24-bit/192kHz), aptX™ HD Wireless Bluetooth and legacy audio equipment via an AUX RCA input. The DX-3 is ideal for audiophiles seeking to enjoy music with a perfect blend of high performance and stylish design. The ultimate personal audio companion, combining an exquisite industrial design with the sophistication of a premium, fully balanced Class A headphone amplifier supported by an ESS Sabre ES9028PRO DAC.
Downstream from the DAC, the analogue output filters are implemented externally using discrete components custom engineered by Rotel to deliver exceptional musical accuracy. Connect your balanced or single ended headphones to the DX 3, or drive a pair of active, powered loudspeakers directly, rendering music up to 32 bit/384 kHz via PC USB, 24 bit/192 kHz through Coaxial/Optical, aptX™ HD wireless Bluetooth, or any legacy audio equipment through the AUX RCA input.
Its fully balanced circuit topology is driven by an in house manufactured toroidal transformer with ultra low noise isolation and high grade filter capacitors. The full colour graphic display, extruded aluminium remote control, and intuitive front panel controls ensure effortless operation and configuration. The DX 3 is ideal for discerning listeners who wish to enjoy music through loudspeakers or in private listening sessions, blending refined performance with contemporary design.
Technical Specifications
| Category | Details |
|---|---|
| Dimensions (W × H × D) | 215 × 73 × 247 mm |
| Dimensions (Inches) | 8 1/2 × 2 3/4 × 9 3/4" |
| Front Panel Height | 70 mm (2 3/4") |
| Power Requirements | 120 V, 60 Hz |
| Power Consumption | 30 W |
| Standby Power Consumption | < 0.5 W |
| Net Weight | 3.2 kg (7.1 lbs.) |
| Thermal (BTU) | 100 BTU/h |
| Power Output – Single-Ended (6.35 mm) | 16 Ω: 765 mW, 32 Ω: 383 mW, 300 Ω: 41 mW |
| Power Output – Balanced (4.4 mm) | 16 Ω: 2.8 W, 32 Ω: 1.4 W, 300 Ω: 150 mW |
| Total Harmonic Distortion (THD) | Single-ended: < 0.008% @ 70 mW (32 Ω, 1 kHz), Balanced: < 0.004% @ 280 mW (32 Ω, 1 kHz) |
| Intermodulation Distortion (60 Hz : 7 kHz, 4:1) | Single-ended: < 0.01%, Balanced: < 0.006% |
| Frequency Response | Headphone: 20 Hz – 20 kHz, +0 dB / –0.2 dB; Digital: 10 Hz – 20 kHz, +0 dB / –0.5 dB; Analog: 20 Hz – 20 kHz, +0 dB / –0.4 dB |
| Signal-to-Noise Ratio (IHF A-Weighted) | Headphone Single-ended: >100 dB, Headphone Balanced: >110 dB, Digital: >112 dB, Analog: >107 dB |
| Headphone Output Impedance | Single-ended: <0.3 Ω, Balanced: <0.6 Ω |
| Gain Levels | 0 dB (High), –6 dB (Medium), –12 dB (Low) |
| Recommended Headphone Impedance | 16 Ω – 300 Ω |
| Input Impedance | Digital: 75 Ω, Analog: 10k Ω |
| Output Level | Unbalanced (RCA): 1.6 V, Balanced (XLR): 3.5 V |
| DAC Chip | ESS ES9028PRO (32-bit / 768 kHz) |
| Digital Inputs Supported | Coaxial / Optical: SPDIF LPCM up to 24-bit / 192 kHz |
| USB (PC-USB) | USB Audio Class 2, Up to 32-bit / 384 kHz PCM, DSD up to 11.2 MHz, DoP up to 5.6 MHz, Driver required for Windows, Roon Tested |
