Rotel DX-5 Integrated Amplifier
- Regular price
- Rs. 177,900.00
- Sale price
- Rs. 177,900.00
- Regular price
-
Couldn't load pickup availability
Description
The Rotel DX-5 is the ultimate Personal Audio Integrated Amplifier blending cutting-edge technologies, versatile connectivity, packaged in a sleek, elegant, industrial design. Engineered for audiophiles, music lovers, and home entertainment enthusiasts, the DX-5 delivers 33 watts @ 4 ohms (25 watts @ 8 ohms) of classic Rotel Class AB amplification in an ultra size-efficient chassis.
The Rotel DX-5 is the ultimate high-performance Personal Audio Integrated Amplifier packaged in a sleek, modern, elegant industrial design. Engineered with passion and driven by a precision Class AB amplifier powered by an in-house wound high-current toroidal transformer delivering 33 watts per channel into 4 ohms (25 watts into 8 ohms).
The premium ESS ES9039Q2M DAC renders the audio with precision and exceptional sound quality on an expansive sound stage. It supports PC-USB (32-bit/384kHz PCM, DSD 4x), Coaxial/Optical (24-bit/192kHz), aptX™ HD and AAC Wireless Bluetooth, legacy RCA analog, and HDMI ARC connectivity with CEC and a subwoofer output.
The DX-5 features a full-color TFT display, 1/4” (6.35mm) headphone jack, and includes an intuitive remote control perfect for music lovers and home entertainment enthusiasts.
Technical Specifications
| Spec | Details |
|---|---|
| Dimensions (W × H × D) | 215 x 76 x 251 mm |
| Dimensions (Inches) | 8 1/2 x 3 x 10" |
| Front Panel Height | 70 mm (2 3/4") |
| Power Requirements | 120 V, 60 Hz |
| Power Consumption | 80 W |
| Standby Power Consumption | < 0.5 W |
| Net Weight | 4.1 kg (9.1 lbs.) |
| BTU | 241 BTU/h |
| Power Output (FTC) | 25 W / ch |
| Maximum Power Output (Non-FTC) | 33 W / ch (1kHz, 4 Ω) |
| Continuous Power Output (Non-FTC) | 25 W / ch (1kHz, 8 Ω) |
| Total Harmonic Distortion | < 0.03% |
| Intermodulation Distortion (60 Hz : 7 kHz, 4:1) | < 0.03% |
| Frequency Response | 10 Hz – 100 kHz (0 ± 0.19 dB) / 10 Hz – 80 kHz (0 ± 2 dB Max) |
| Damping Factor (20 Hz – 20 kHz, 8 Ω) | 140 |
| Input Sensitivity / Impedance | 680 mV / 100k Ω (analog), -10.3 dBFS / 75 Ω (digital) |
| Input Overload | 4.2 V |
| S/N Ratio (IHF "A" Weighted) | > 100 dB |
| HDMI | ARC (Audio Return Channel) supported |
| Digital Inputs | SPDIF LPCM (up to 24-bit / 192 kHz) |
| PC-USB | USB Audio Class 2.0, up to 32-bit / 384 kHz* |
| *Supports DSD (up to 4X, 11.2 MHz) and DoP (up to 2X, 5.6 MHz) | |
| Roon | Roon Tested |
